The CTAB is a versatile cable tester designed to save you time and frustration when troubleshooting audio, video, network, and other low-voltage cabling issues. Its compact, handheld design packs a punch, offering a wide range of testing capabilities for both professional and home users.

Whether you’re a seasoned technician or a DIY enthusiast, the CTAB is your one-stop solution for ensuring flawless connections in your equipment.

It’s unique 2 piece chassis design is particularly useful when checking long install runs. It comes with audio signal generator and audio power amplifier. It can easily test the connection and working condition of the entire audio system and find out the fault point quickly.

Features:

• Versatile Testing: Handles audio, video, network, and low-voltage cabling issues.
• Comprehensive Capabilities: Offers a wide range of testing functions.
• User-Friendly Design: Easy to use, even for beginners.
• Unique 2-Piece Chassis: Ideal for testing long cable runs.
• Audio Testing: Includes signal generator and amplifier for audio system checks.
• Fault Detection: Quickly identifies connection and working issues.

Supports 16 cable types, including:

• HDMI
• XLR
• RCA
• BNC
• RJ45
• Speakon
• Powercon
• 3.5mm Jack
• 1/4” Jack
• DIN
• Type C

Test in-wall cable
Max Distance ≈ 3000m
Max Distance ≈ 1000m (Audio Cables)

Dimension (A and B together): 190x128x35mm (7.5x5x1.4 in)

Barcode: 686811897611
